Item

Unit

Parameter

Max. Productivity

m3/h

240

Nominal capacity of mixer

m3

2×2.0

Max Weighing Value of aggregate

kg

8×2000

Max Weighing Value of cement

kg

2×1500

Max Weighing Value of fly ash

kg

2×600

Max Weighing Value of powder additiv

kg

2×300

Max Weighing Value of water

kg

2×500

Max Weighing Value of additive

kg

4×50

Rating transport capacity of screw conveyor

t/h

50

Capacity of Cement Cabin

t

8×250

Mixing Power

kW

4×37

Hoist Power

kW

2×30

Power of Machine

kW

480

Weight of Machine

t

80

Discharge Height

m

3.8

Aggregate measuring accuracy

%

±2

Water measuring accuracy

%

±1

Cement measuring accuracy

%

±1

Additive measuring accuracy

%

±1

Outline Dimension（L×W×H）

m

61.2×34.5×21.3

No.

Item

Spec.

Unit

Amount

1

Aggregate batching machine

PLD3200A-Ⅳ

set

2

2

Body part

set

1

2.1

Mixer

JS2000A Mixer

set

2

2.2

Cement Weighing System

Max Weighing Value 1500kg

set

2

2.3

Fly ash Weighing System

Max Weighing Value 600kg

set

2

2.4

Powder Additive Weighing System

Max Weighing Value 300kg

set

2

2.5

Additive Weighing System

Max Weighing Value 50kg

set

2

2.6

Water Weighing System

Max Weighing Value 500kg

set

2

2.7

Aggregate hoisting system

18° belt conveyer

set

2

2.8

Steel structure

set

1

3

Cement silo

SC100

set

8

4

Screw conveyer

LSY250-9

set

8

5

Water supply

set

1

5.1

Water tank

20m3

set

1

5.2

Water pump

KQL80-100（Ⅰ）

set

2

6

Additive supply system

set

6

6.1

Additive storage

10m3

set

6

6.2

Additive pump

32CQ-15

set

6

7

Air system

set

2

7.1

Compressor

W-2.0/7

set

2

7.2

Air line accessories

set

2

8

Control system

HZS120 Control cubicle

set

2

8.1

Electric tank

set

2

8.2

Control cubicle

set

2

8.3

Computer

Legend Group computer

set

2

8.4

Load sensor

set

2

8.4

Computer Box

set

2

8.5

Button

set

2

8.6

Computer software

set

2

8.7

Programmer system

set

2

8.7

Printer

set

2

8.8

Computer desk

set

2

8.9

Swivel chair

set

2
