Items

Unit

Specifications

Mixing drum

Capacity

m3

13.00

Effective mixing capacity

m3

5.5

Max. drum diameter

mm

φ2280

Drum length

mm

4680

Drum obliquity

°

13

Drum rotating speed

r/min

0~14

Discharging capability

Slump 5cm

S/m3

Approx.30

Slump 8~22cm

Approx.20

Fluid power system

Hydraulic pump

Model

Imported

Oil motor

Model

Imported

Reduction box with motor

Model

Imported

Hydraulic tank

L

54

Water supply system

Supply mode

Micro electric pump

Water pump

WP24-180B12

Water tank

L

250

Chassis

Chassis Model

CA1253P2K2T1S2

Wheel base

mm

3600+1350

Max. running speed

km/h

≥85

Min. turning diameter

m

≤16.3

Min. ground clearance

mm

245

Engine

Engine Model

CA6DL1-31

Max. output

kw

228

Max. torque

N·m

1100

Displacement

L

7.7

Environmental standard

Euro II

Overall dimensions (L×W×H)

mm

8800×2490×3650
