Items

Unit

Specifications

Mixing drum

Capacity

m3

13.00

Effective mixing capacity

m3

5.5

Max. drum diameter

mm

Φ2280

Drum length

mm

4680

Drum obliquity

°

13

Drum rotating speed

r/min

0~14

Discharging capability

Slump 5cm

S/m3

Approx.30

Slump 8~22cm

Approx.20

Fluid power system

Hydraulic pump

Model

Imported

Oil motor

Model

Imported

Reduction box with motor

Model

Imported

Hydraulic tank

L

54

Water supply system

Supply mode

Micro electric pump

Water pump

WP24-180B12

Water tank

L

250

Chassis

Chassis Model

CA1250P2K2T1S2

Wheel base

mm

3400+1350

Wheel track front / rear

mm

2020/1847

Max. running speed

km/h

73

Min. turning diameter

m

16.8

Min. ground clearance

mm

250

Engine

Engine Model

CA6DL1-31

Max. output

kw

228

Environmental standard

Euro II

Overall dimensions (L×W×H)

mm

8678×2490×3655
