Rated productivity (with 5% moisture content)

280-320t/h

Cold feed bin

5bins/74m3

Output capacity of Cold feed bin

440t/h

Dryer drum spec

2740mm*11500mm（φ*L)

Dryer drum capacity

360t/h (with 3% moisture content)
>330t/h(with 5% moisture content)

Bag filter brand and filtering area

NOMEX/1198m2

Emission standard

≤≤50mg/Nm3

Screening-weighting-mixing system

Screen section

5 floors

Hot bin

5 bins+1 /58m3

Bitumen weighting

0-400kg（auto injection)

Mixer capacity

3600(kg)

Mixing cycle time

38-45s

Filler silo capacity

50m3

Bitumen tanks capacity

4*50m3

Oil heater

9*105kcal/h

Mixed material silo

121m3

Control system:manual/semi-auto/auto.

English automatic

Weighting accuracy

Aggregate

≤±0.5%

Filler

≤±0.25%

Bitument

≤±0.25%

Total Installed power

882.78kw

Installed outsize

50*45*14m
