Rated productivity (with 5% moisture content)

165-180t/h

Cold feed bin

5bins/50m3

Output capacity of Cold feed bin

310t/h

Dryer drum spec

2200mm*9000mm（φ*L)

Dryer drum capacity

185t/h (with 3% moisture content)
>160t/h(with 5% moisture content)

Bag filter brand and filtering area

NOMEX/912m2

Emission standard

≤≤100mg/Nm3

Screening-weighting-mixing system

Screen section

4 floors

Hot bin

4 bins+1 /20m3

Bitumen weighting

0-200kg（auto injection)

Mixer capacity

1950(kg)

Mixing cycle time

38-45s

Filler silo capacity

24m3

Bitumen tanks capacity

2*50m3

Oil heater

6*105kcal/h

Mixed material silo

70m3

Control system:manual/semi-auto/auto.

English automatic

Weighting accuracy

Aggregate

≤±0.5%

Filler

≤±0.25%

Bitument

≤±0.25%

Total Installed power

556kw

Installed outsize

42*40*14m
