Classificatory	Item		Unit	Parameter
Outline dimension	Overall length		mm	14550
	Overall width		mm	2750
	Overall height		mm	3750
	Wheel base	Axle 1, Axle 2	mm	1520
		Axle 2, Axle 3	mm	2600
		Axle 3, Axle 4	mm	1600
		Axle 4, Axle 5	mm	1350
		Axle 5, Axle 6	mm	1350
	Track	Axle 1, Axle 2, Axle 3	mm	2300
		Axle 3, Axle 4, Axle 5	mm	2055
Mass	Total mass in travel state		kg	60000
Travel performance	Travel speed	Max. travel speed	km/h	85
		Min. stable travel speed	km/h	4
	Turning radius	Min. turning radius	m	13
		Min. turning radius at boom tip	m	15
	Min. ground clearance		mm	270
	Approach angle		(°)	19
	Departure angle		(°)	20
	Braking distance (at 30km/h with full load)		m	≤12
	Max. grade-ability		%	22
	Fuel consumption for 100km		L	75
Power	Upper engine rated output		kW/(r/min.)	158/2200
	Upper engine rated torque		N.m/(r/min.)	770/1540
	Upper engine rated speed		rpm.	2200
