Travel Operation
Category			Items	Unit	Parameters
Chassis			Model		FM
			Make		VOLVO
			Max.speed	km/h	90
			Max.gradeability		30%
			Min.turning diameter	m	18.4
			Brake distance	m	≤7
			Axle base	mm	4900+1370
			Wheelbase (front/rear)	mm	2019/1834
			Approach/departure angle	°	18/10
			Min.ground clearance	mm	270
			Tire		315/80R22.5
Engine			Model		D13
			Output power	kw/(r/min)	294/1800
			Max.torque	N.m/(r/min)	2000/1050
			Displacement	L	12.8
			Emission standard		China Ⅲ  GBⅢ
Others			Dimension (L×W×H)	mm	11060×2500×3990
			Overall weight	kg	32600
			Fuel tank volume	L	400
			Fuel consumption (100km)	L/100km	40
Working Condition
Pumping system	Theoretical capacity（High/low pressure）			m3/h	70/140
	Pumping pressure（High/low pressure）			Mpa	11.8/6.38
	Theoretical frequency（High/low pressure）			Times/min	15/27
	Max.aggregate diameter			mm	40
	Loading height			mm	1530
	Slump			mm	12-23
Placing boom	Reach height			m	40.5
	Reach depth			m	27.5
	Slewing radius			m	36
	Slewing angle			°	±270
	Stretch angle of 1st boom			°	90
	Stretch angle of 2nd boom			°	180
	Stretch angle of 3rd boom			°	180
	Stretch angle of 4th boom			°	240
	Stretch angle of 5th boom			°	250
	Outrigger span	Longitudinal		mm	7800
		Transverse span of front outrigger		mm	8530
		Transverse span of rear outrigger		mm	7200
Others	Batching				S valve
	Lubrication				Automatic lubrication
	Control				Manual/remote control
	Water tank volume			L	600
	Max.pressure of water pump			MPa	2
