Travel Operation
Category		Items		Unit		Parameters
Chassis		Model				Actros4141
		Make				Germany BENZ
		Max.speed		km/h		85
		Max.gradeability				38%
		Min.turning diameter		m		25.9
		Brake distance		m		≤10
		Axle base		mm		1700+4600+1350
		Wheelbase (front/rear)		mm		2034/1804
		Approach/departure angle		°		22/10
		Min.ground clearance		mm		300
		Tire				315/80R22.5
Engine		Model				OM501LA.Ⅲ/17
		Output power		kw/(r/min)		300/1800
		Max.torque		N.m/(r/min)		2000/1080
		Displacement		L		11.946
		Emission standard				China Ⅲ  GBⅢ
Others		Dimension (L×W×H)		mm		12590×2500×3995
		Overall weight		kg		38400
		Fuel tank volume		L		400
		Fuel consumption (100km)		L/100km		40
Working Condition
Pumping system	Theoretical capacity（High/low pressure）				m3/h	75/138
	Pumping pressure（High/low pressure）				Mpa	11.6/6.5
	Theoretical frequency（High/low pressure）				Times/min	11/20
	Max.aggregate diameter				mm	40
	Loading height				mm	1540
	Slump				mm	12-23
Placing boom	Reach height				m	45.1
	Reach depth				m	32.7
	Slewing radius				m	40.1
	Slewing angle				°	370
	Stretch angle of 1st boom				°	90
	Stretch angle of 2nd boom				°	180
	Stretch angle of 3rd boom				°	180
	Stretch angle of 4th boom				°	250
	Stretch angle of 5th boom				°	250
	Outrigger span		Longitudinal		mm	9500
			Transverse span of front outrigger		mm	10100
			Transverse span of rear outrigger		mm	9140
Others	Batching					S valve
	Lubrication					Automatic lubrication
	Control					Manual/remote control
	Change of High/low pressure					Automatic
	Water tank volume				L	600
	Max.pressure of water pump				Mpa	2
