Travel Operation
Category		Items	Unit	Parameters
Chassis		Model		FY1EWV
		Make		日野
		Max.speed	km/h	85
		Max.gradeability		39.9%
		Min.turning diameter	m	24.4
		Brake distance	m	≤10
		Axle base	mm	1850+4605+1310
		Wheelbase (front/rear)	mm	2050/1855
		Approach/departure angle	°	18/10
		Min.ground clearance	mm	240
		Tire		315/80R22.5
Engine		Model		E13CTR
		Output power	kw/(r/min)	331/1800
		Max.torque	N.m/(r/min)	1912/1100
		Displacement	l	12.913
		Emission standard		China Ⅲ  GBⅢ
Others		Dimension (L×W×H)	mm	12725×2500×3995
		Overall weight	kg	40000
		Fuel tank volume	l	400
		Fuel consumption (100km)	l/100km	40
Working Condition
Pumping system	Theoretical capacity（High/low pressure）		m3/h	90/150
	Pumping pressure（High/low pressure）		Mpa	13/8
	Theoretical frequency（High/low pressure）		Times/min	13/22
	Max.aggregate diameter		mm	40
	Loading height		mm	1540
	Slump		mm	12-23
Placing boom	Reach height		m	48.1
	Reach depth		m	34
	Slewing radius		m	43.75
	Slewing angle		°	370
	Stretch angle of 1st boom		°	90
	Stretch angle of 2nd boom		°	180
	Stretch angle of 3rd boom		°	180
	Stretch angle of 4th boom		°	250
	Stretch angle of 5th boom		°	250
	Outrigger span	Longitudinal	mm	10500
		Transverse span of front outrigger	mm	10450
		Transverse span of rear outrigger	mm	10300
Others	Batching			S valve
	Lubrication			Automatic lubrication
	Control			Manual/remote control
	Change of High/low pressure			Automatic
	Water tank volume		L	600
	Max.pressure of water pump		MPa	2
