|→　Road building machinery → Roller → Vibratory Compactor → Single drum

XS220

Requset a Quote

Type	Unit	XS220
Working mass	kg	22500
Axle load, front drum	kg	15100
Axle load, rear drum	kg	7400
Static linear load	N/cm	695
Speed range	Km/h	0-12
Theoretical gradeability	%	50
Min. turning radius	mm	6870
Min. Clearance	mm	450
Max.shell protuberating	mm	150
Steering angle		±30°
Oscillating angle		±9°
Oscillating angle frequency	Hz	28/35
Nominal amplitude (High/Low)	mm	2.0/0.96
Centrifugal force High/Low amplitude	kN	415/280
Vibrating drum diameter	mm	1600
Vibrating drum width	mm	2130
Engine		Cummins
Overall dimensions(LWH)	mm	629524303188

XS220:
Optional equipment： imported compactionmeter

Note: All specifications on our website are subject to technical modifications without notice.
